Standard RGB 5050SMD LED Strip
Standard RGB 5050SMD LED Strip

Standard RGB 5050SMD LED Strip

Standard RGB 5050SMD LED Strip

Select the number of specifications

Please check the product information you want!

Product Detail Specification Sheet

Specifications:

  • Hight brightness LED, High lumen output;
  • Single row,double row optional;
  • DC24V ;
  • Waterproof Grade: IP65/IP67/IP68;
  • Customized service available,
  • CE,ROHS,ETL approved
  • 5years warranty
LED TypeSMD5050
LED Quantity60Leds/M
ColorRGBWWW(5IN1)
Wavelength(nm)R(620-630nm)G(520-530nm)B(465-475nm)
CCT(K)2700-6500K
Lumen/Meter968lm/meter
Actual Power(w/m)18.5/Meter
PCB Width12mm
VoltageDC24V
Cuttable Size100mm/DC24
IP Grade
IP65/IP67/IP68
Beam Angle120°
Working Temperature-25 °C ~ +45°C
Length5meter/roll


Please contact us for the specification sheet
